Keyfeatures
Capacity Range: 2-50 tons, Covers regional, wide-body, and mixed-fleet aircraft.
Adjustable Lifting Heights: Hydraulic lift of up to 2,050 mm (80.7 inches) with screw extension options.
Manual, Hydraulic & Electronic Configurations: Available with hand pumps, air-hydraulic, electro-hydraulic, and full EJAL integration.
Advanced Safety Systems: Features manual or automatic safety lock nuts, overload protection valves, and electronic stroke measurement.
Corrosion-Resistant & Durable Design: Hard-chromium-plated cylinder tubes and Skydrol-resistant coatings for extended service life.
Compact & Maneuverable: Spring-loaded castors, adjustable tow bars, and forklift adapters ensure easy handling and positioning.
Highlights
Designed for Regional & Mixed-Fleet Operators: Supports diverse aircraft categories with scalable configurations.
Modular & Future-Proof Design: Customizable for incremental automation upgrades.
At Least 10 Years of Spare Parts Availability.
Factory Proof Load Certification at 150% Capacity.
Fully CE-Marked & OEM Validated for Airbus & Boeing Aircraft.
On-Site Service & Global Support Network.
Application Cases
Routine Line Maintenance & Fleet Servicing
Structural Overhauls & Heavy Checks
Body, Wing & Tail Lifting for a Wide Range of Aircraft
Regional Jets: Embraer 170/190, Fokker 70/100, Dash 8, BAE-146
Commercial Aircraft: A300, A310, B737, B757, MD-90
Business Jets: PC-12, PC-21, Dornier DO228
Configuration Options
Safety & Operational Enhancements
• Manual or Automatic Safety Lock Nut for secure load holding.
• Electronic Stroke Measurement System for precise lifting control.
• Load Indication & Overload Warning Systems for advanced monitoring.
Mobility & Transport
• Spring-Loaded & Hydraulically Adjustable Swivel Castors for effortless maneuvering.
• Forklift Adapter & PowerCat Towing Interface for efficient transport.
• Fixed and Mobile Laser Target Systems for accurate alignment.
Automation & Load Management
• Electronic Jacking and Leveling System (EJAL) Compatibility – For synchronized aircraft lifting.
• Mechanical & Electronic Stroke Measurement – Ensures uniform lifting heights.
• Fast Lowering System & Auto-Leveling Options – For controlled load handling.
The D/DT series’ modular upgrade options provide long-term flexibility, allowing operators to adapt their lifting solutions to evolving maintenance needs.
Why RH Aero?
The Best Choice for Operators Requiring Versatility & Scalability The D/DT Tripod Jack Family is the most adaptable and configurable lifting solution in RH Aero’s lineup. Designed for MROs, fleet operators, and mixed-use maintenance environments, it provides the ideal balance of mobility, modularity, and long-term investment protection.
