Keyfeatures
16 t capacity beam built from high‑strength steel.
Interface to R19.5 mm axle‑jacking point—fits the full A320‑ and 737‑families.
Four carry handles and castors for effortless positioning.
Twin bubble‑level indicators for precise, horizontal lifting.
Two floating axle‑jack interfaces guarantee even load distribution.
Fly‑away transport box with forklift pockets for quick deployment.
Factory proof‑loaded to 150 % of rated capacity.
Highlights
Fleet fit: A318–A321 (inc. NEO), B737 Classic/NG/MAX.
Low profile: 85 mm beam height slips beneath flat rims without tyre removal.
10‑year spare‑parts availability and on‑site service.
Application Cases
Dual‑flat‑tyre recoveries at the gate, ramp, or taxiway.
AOG fly‑away missions—beam packs in a single crate for remote support.
Training—simple design helps instruct crews in safe recovery procedures.
Configuration Options
Safety & Operational Enhancements
- R19.5 mm precision interface keeps jacks centred on the nose‑gear axle.
- Twin bubble levels help maintain horizontal orientation during the lift.
Mobility & Transport
- Built‑in castors and four ergonomic handles speed beam placement.
- Rugged fly‑away case with forklift pockets protects the beam in transit.
Setup Efficiency
- Floating jack pads align automatically with RT, RH or RC axle jacks.
- No special tools needed—beam is ready for use straight out of the case.
Why RH Aero?
RH Aero keeps RAJB beams and transport cases in stock for immediate dispatch and provides round‑the‑clock technical support to integrate the beam with your existing HYDRO axle jacks—so your narrow‑body fleet gets back on its wheels, and back in service, faster.
