Keyfeatures
Intelligent Lifting System (ILS) – Built-in load cells, stroke sensors, and inclination monitoring provide real-time feedback and automatic overload shut-off.
High-Capacity Range – Models from 35 t to 165 t cover everything from regional jets to the A380 and 777-9.
Single-Lift Recovery – Extra-long telescopic cylinders and ± 600 mm x/y adjustment reach all jacking points without repositioning.
Synchronized Remote Control – One operator can raise multiple tripods in perfect unison from a safe distance.
Rapid Global Deployment – Tool-less disassembly fits a complete RJ set on six ULD pallets; 400 V/50-60 Hz power suits ground generators worldwide.
Data-Logging & Traceability – Lift parameters are recorded for post-incident reports and insurer documentation.
All-Weather Durability – IP65-sealed electrics, –20 °C to +60 °C operating range, and corrosion-resistant coatings ensure reliability on any ramp.
150 % Proof-Load Certified – Every unit meets EN 12312-19 and ANSI/ASME PALD standards for safety and side-load capacity.
Highlights
One System for Every Recovery Scenario
OEM | Representative Aircraft Types |
Airbus | A220, A320 family, A330, A350, A380 |
Boeing | 737 NG/MAX, 747-8, 757/767, 777, 787 |
Others | Embraer E-Jets, CRJ 700/900, C-Series freighters, military transports |
The RJ family’s capacity and height envelope accommodate nose-, wing-, and tail-jack positions on both narrow- and wide-body fleets.
Application Cases
Runway Excursions & Gear-Collapse Incidents – Restore roll capability and clear the airfield fast.
Soft-Ground or Off-Pavement Recovery – Provide stable vertical lift while winches or airbags handle lateral extraction.
Configuration Options
Safety & Control Enhancements
- ILS Redundant Load Cells – Dual sensors in each cylinder verify readings and trigger automatic shutdown on overload.
- Emergency Stop & Pressure-Relief Valves – Instant circuit isolation prevents uncontrolled descent.
- Tilt & Skew Monitoring – Integrated accelerometers halt the lift if fuselage attitude exceeds preset limits.
Mobility & Setup
- Break-Down Tripod Sections – Legs, cylinders, and crosshead disconnect without tools for air freight.
- Self-Levelling Outriggers – Quick pin-in-place feet compensate for uneven terrain.
- Heavy-Duty Caster Kits – Optional wheel sets for short-range hangar moves.
Load Management & Monitoring
- Touchscreen Control Console – Displays live load, height, and angle; stores lift profiles for export (USB or Wi-Fi).
- Remote Pendant – Handheld, tethered unit allows one-tech operation from beyond the safety cordon.
- Calibration Interface – Compatible with HYDRO field-proof-load rigs for annual recertification.
Why RH Aero?
Protect the Airframe—Restore Operations
RJ Tripod Jacks combine massive lifting power with digital intelligence, giving recovery specialists the confidence to act quickly without compromising aircraft integrity. Backed by RH Aero Systems’ global AOG network and guaranteed spare-parts support, RJ is the industry’s definitive choice for safe, efficient aircraft recovery—any tail, any time, anywhere.
