Keyfeatures
Split-Engine Coverage – Core, Fan, and Storage Container support XWB split logistics from shop to flight line.
Airfreight Options – SES supports B747F/B777E for split; AN124 or Beluga for whole engine or QECU on the Core.
Shock Attenuation – Shock-attenuated cradles and shock-absorbing castors protect engines during transport and storage.
Forklift & Lifting Interfaces – Integrated forklift tubes with limiters and crane lift points enable safe handling with or without engine.
Tow-Ready Mobility – Integrated castors and tow-bars enable controlled local moves with or without engine fitted.
Highlights
Family covers Trent XWB-84k/-97k on A350-900/-1000 and Trent 1000 on B787-8/-10 across transport, storage, and on-wing tasks.
Airbus
A350-900 • A350-1000
Boeing
B787-8 • B787-10
Application Cases
Split-Engine Logistics – Fan, core, and parts container moves for A350-900/-1000 with Trent XWB-84k/-97k.
Basic Transport & Exchange – Road/sea transfer, storage, and on-wing tasks for B787-8/-10 and Trent XWB configurations.
Configuration Options
Safety & Operation
Hydraulic pump operation raises and lowers SES to remove or fit the fan case to the engine.
Stands can be lifted with or without engine or fan using a forklift or crane with appropriate tooling.
Bootstrapping kits support aircraft installation and removal where specified for XWB and Trent 1000 engines.
Integrated forklift tubes include limiters to avoid engine damage during handling.
Storage container secures split parts with dedicated internal boxes and an included MVP bag for preservation.
Mobility & Transport
Integrated castors and tow-bars provide towing capability and precise positioning during local moves.
Airfreight palletization supports B747F/B777E for SES; Basic stands are approved for road and sea transport.
Optional Long Range Towing Unit and Master Mover interface extend towing distance and control on XWB Basic stands.
Durability & Corrosion Protection
Shock-attenuated cradles and retractable, shock-absorbing castors reduce vibration loads during storage and movement.
Integrated storage boxes protect trunnions and accessories throughout transport and layup.
Container sling and lid hardware enable repeatable opening without damaging seals or surfaces.
Why RH Aero?
Split Precision—Global Transport
RRT brings SES modules and Basic stands into one coherent toolkit for XWB and Trent 1000 operations. Integrated pallets, forklift tubes, shock isolation, and defined bootstrapping kits streamline handling while protecting valuable assets. A broad accessory set—lifters, straps, MVP bags, and towing options—adapts to airline and MRO workflows for predictable, compliant moves.
