Keyfeatures
High‑strength tube construction (steel or split‑aluminium fly‑away) for durability with low weight.
Revolving or fixed clamp‑type tow head with built‑in shear pins and retaining pin for push/pull & torque safety.
3‑inch rigid tow eye fits standard tractors; optional revolving/buffered eye available.
Hydraulically height‑adjustable undercarriage with floating axle and pneumatic tyres for quick, mis‑alignment‑free coupling.
Maintenance‑free hand‑pump with spring & dead‑man circuit for safe, precise lowering.
Spare shear‑pin holder on the tube keeps four pins ready for rapid change‑out.
Skydrol‑resistant paint & OEM labelling ensure long life and clear fleet allocation.
Highlights
Narrow‑body: A220, A318 – A321 (incl. NEO/LR/XLR), B737 Classic/NG/MAX, C919, MC‑21, SSJ‑100.
Wide‑body: A330/340/350 families, B767, B777‑200 – ‑9, B787‑8/‑9/‑10, DC‑10‑30/‑40 & MD‑11.
Regional/Biz: Embraer E190‑E2/ E195‑E2 via split‑tube TOWUNIV9.
Application Cases
Routine pushback & towing for mixed narrow‑ and wide‑body stands.
AOG / fly‑away recovery—lightweight bars stow in cargo holds for remote dispatch.
MRO hangar operations where one bar must service multiple fleet types.
Lease return & demonstration flights—universal fit avoids sourcing dedicated bars at each stop.
Training & standardisation—common controls and spares streamline ramp‑staff instruction.
Configuration Options
Safety & Operational Enhancements
Shear pins for push/pull + torque with retaining pin for maximum safety.
Shear‑pin values set to the lowest OEM limit across covered types.
Mobility & Positioning
Hydraulically height‑adjustable undercarriage with floating axle absorbs lateral mis‑alignment.
Pneumatic high‑performance tyres for smooth, long‑distance towing.
Revolving tow head (TOWUNIV3/7) or fixed head (TOWUNIV4/5/6/8) to match fleet mix.
Service & Lifecycle
Maintenance‑free hand pump; exchange‑service for refurbished units.
10‑year spare‑parts availability and on‑site service support from HYDRO.
Fly‑Away Options
TOWUNIV5F short 2 m bar with auxiliary wheel for B777/B787 missions.
TOWUNIV9S three‑piece aluminium bar for A320‑family & Embraer E2 recovery kits.
Why RH Aero?
RH Aero supplies TOWUNIV bars off‑the‑shelf or custom‑configured, ships spare pins and pumps worldwide 24/7, and backs every bar with expert integration support—giving operators one dependable partner to keep mixed fleets moving safely and on schedule.
